| Chassis | Longitudinal members of hot rolled/welded I beams grade ST 52-3 or equivalent. All other pressed steel channels/plates of Grade ST 37-2 or equivalent. |
| Gooseneck | Fixed type narrow gooseneck with 6mm steel chequered plate flooring and and provision for spare wheel carrier. |
| Deck | Floor – 8 mm Chq-plate supported by suitable pressed steel cross members. |
| Loading ramp | 2 nos. 800mm wide, fabricated structure covered with 6 mm thick chequered plate and grip strips at suitable interval for safe loading/unloading, Ramps are operated Manually or Hydraulically. |
| Axles | 3 x 16 ton axles, “VB” multi leaf spring Mechanical underslung suspension, wide track. BPW German or as per customer request. |
| Tyres | 12+ 1 nos. 12.00 x R 20” |
| Rims | 12+1 nos. 8.50 x 20” Steel Disc rims (10 bolts) |
| Brakes | Twin line drum brakes, acting on all wheels with ‘S’ cam actuation.
– Two single acting diaphragm brake chambers per axle – Service & emergency delay valves – Automatic load sensing valve – Air reservoir. – Manual parking brake. |
| Landing gear | Two speed Landing legs. Jost / Equi. |
| King pin | Jost / SAF 3.5” dia. to SAE standard Interchangeable to 2” |
| Lashing rings | 5 nos. lashing rings on either side of lowbed. |
| Electrical | 7 way quick release connector, pair of 24 volt rear light units, each comprising tail light, brake and signal light fitted at rear Aspock or equivalent.
– 5 nos. Side markers on either side. – Registration plate lamps. – 1 No. Rotating beacon. – Reverse light with horn. |
| Painting System | Surface treatment-Grit blasted to S.A.2.5 (Swedish std)
Two coat of epoxy primer and top coat of high gloss Polyuretane finish paint in single colour. (Customer to Specify RAL Code). |
| Accessories | – 2 no. Spare wheel carrier (winch type) on goose neck
– 1 no. Tool box provided in the goose neck without tools. – Manual support legs at rear (2 nos.) – Side under run protection on both sides |
